The working principle of the backstop of the reducer

Inside the backstop on the reducer, there are a number of special-shaped blocks distributed in the raceway formed by the inner and outer rings. When the inner ring is running in the forward direction, it drives the special-shaped blocks to rotate together. When the speed is within a certain range, the special-shaped blocks are Under the action of centrifugal force, it is deflected and out of contact with the inner and outer rings, so as to realize wear-free operation.

T=F*R R is the radius and diameter unit of the turntable 'm' F is the force unit 'Newton' generated when the heavy object is lifted by the turntable when the reducer outputs the maximum torque.

Extended information:

Backstop storage precautions:

1. Date and name of the manufacturer. The size and technical requirements of the sign shall comply with the provisions of GB/T and 13306.

2. The backstop delivered in a single unit should be packaged and shipped, and the inner hole of the inner ring and the pin shaft should be coated with anti-rust grease during packaging. The backstop shipped with the main engine should meet the packaging requirements of the main engine.

The role of the reducer:

1. Decrease the speed and increase the output torque at the same time. The torque output ratio is multiplied by the motor output multiplied by the reduction ratio, but pay attention not to exceed the rated torque of the reducer.

2. Deceleration reduces the inertia of the load at the same time, and the reduction of inertia is the square of the reduction ratio.
